Voltage: 14
Amp: 30
Pulley dist.: 61.00
Width/holder arm: 40.00
Bracket hole: 9.00
Belt. adj. brackethole pos.: 10
Belt. adj. bracket hole 1: 7.50
Pulley dia.: 66.70
Grooves/pulley: 1
Radius: 73.00
Radius 2: 75.00
B+: M6
Position/B+ in min.: 10
D+ Size: 6.30
Total length mm: 155.00
Pulley: P
Regulator: w/o
Prod. info: BN
Servicing: Citroen
Remarks: Regulator: HC-CARGO 130679.
OEM
a11m11, a11m12, a11m4, a11m5, a11m6, a12r56, aag0702, ald12n-53, aln12-1, am532-010ar, AM532010AR, AY532010R, F032110743, 9al2696g, 11.201.021, 112, 7522, 7532, 7534, 7536, 7542, 310058l, 310221w, 310231z, 451003, 5446241, 5446248, 5473145, 5490438, 5490668, 5491162, 5491319, 75491667, 75491721, 75492583, 95492810, 95580160, 95591699, 95618728, 9120331301
Konkurrentreferens
A9086, A9220, ALT-H010, ALT14083, CAL15217, dra1931, dra1932, DRA2081, F042A0H010, FRA202, ia0021, IA9438, lra00123, lra00267, MG497, NA117, QA1408, va164, va180, 8EL012429-671, 8el725568-001, 8el725570-001, 16-31.931, 27-0513, 216.001.302, 216.004.302, 516.002.302, 3156, 4118, 5080, 20123N, 30112, 30115, 55651, 55660, 55662, 118097, 118102, 432834, 433351, 433352, 12031930, 32121099, 943356115, 943356120, 0986031931, 0986032020, 0986032021, 0986121099, 0986121149
Normaliserat artikelnummer
a11m11, a11m12, a11m4, a11m5, a11m6, a12r56, a9086, a9220, aag0702, ald12n53, aln121, alt14083, alth010, am532010ar, ay532010r, cal15217, dra1931, dra1932, dra2081, f032110743, f042a0h010, fra202, ia0021, ia9438, lra00123, lra00267, mg497, na117, qa1408, va164, va180, 8el012429671, 8el725568001, 8el725570001, 9al2696g, 112, 3156, 4118, 5080, 7522, 7532, 7534, 7536, 7542, 20123n, 30112, 30115, 55651, 55660, 55662, 118097, 118102, 270513, 310058l, 310221w, 310231z, 432834, 433351, 433352, 451003, 1631931, 5446241, 5446248, 5473145, 5490438, 5490668, 5491162, 5491319, 11201021, 12031930, 32121099, 75491667, 75491721, 75492583, 95492810, 95580160, 95591699, 95618728, 216001302, 216004302, 516002302, 943356115, 943356120, 0986031931, 0986032020, 0986032021, 0986121099, 0986121149, 9120331301
Passar modeller
| Citroen Model: 2 CV Model series: 2 CV AKZ Model type: 2 CV Size of motor: 0.6 Brand of engine: M28/1 (AK2) Body: Box Body / Estate From date: 01-03-1970 To date: 01-12-1977 Fuel: Gasoline Approved: Yes |
| Citroen Model: 2CV Model series: 2CV 4 Size of motor: 0.4 Brand of engine: A53 From date: 01-03-1963 To date: 01-02-1970 Fuel: Gasoline Approved: Yes |
| Citroen Model: 2CV Model series: 2CV 4 Size of motor: 0.4 Brand of engine: A79/1 From date: 01-01-1970 To date: 01-12-1975 Fuel: Gasoline Approved: Yes |
| Citroen Model: 2CV Model series: 2CV 6 Size of motor: 0.6 Brand of engine: A06/635 From date: 01-02-1970 To date: 01-10-1985 Fuel: Gasoline Approved: Yes |
| Citroen Model: 2CV Model series: 2CV 6 Size of motor: 0.6 Brand of engine: A06/664 From date: 01-02-1970 To date: 01-10-1985 Fuel: Gasoline Approved: Yes |
| Citroen Model: 2CV Model series: 2CV 6 Size of motor: 0.6 Brand of engine: A06/664 From date: 01-08-1979 To date: 01-07-1990 Fuel: Gasoline Approved: Yes |
| Citroen Model: 2CV Model series: 2CV 6 Size of motor: 0.6 Brand of engine: M28/1 From date: 01-09-1975 To date: 01-06-1981 Fuel: Gasoline Approved: Yes |
| Citroen Model: Ami Model series: Ami 6 Size of motor: 0.6 Brand of engine: M28 Body: Estate From date: 01-05-1968 To date: 01-07-1969 Fuel: Gasoline Approved: Yes Manufacture type: break |
| Citroen Model: Ami Model series: Ami 8 Size of motor: 0.6 Brand of engine: M28 Type description: AM3 Body: Estate From date: 01-07-1969 To date: 01-12-1977 Fuel: Gasoline Approved: Yes Manufacture type: break |
| Citroen Model: Ami Model series: Ami 8 Size of motor: 0.6 Brand of engine: M28 Type description: AM3 From date: 01-07-1969 To date: 01-12-1977 Fuel: Gasoline Approved: Yes |
| Citroen Model: Ami Model series: Ami Super Size of motor: 1.0 Brand of engine: G10 Type description: G10 Body: Estate From date: 01-03-1973 To date: 01-12-1977 Fuel: Gasoline Approved: Yes Manufacture type: break |
| Citroen Model: Ami Model series: Ami Super Size of motor: 1.0 Brand of engine: G10 Type description: G10 From date: 01-03-1973 To date: 01-12-1977 Fuel: Gasoline Approved: Yes |
| Citroen Model: Dyane Model series: Dyane 4 Size of motor: 0.4 Brand of engine: A79/1 From date: 01-04-1968 To date: 01-07-1975 Fuel: Gasoline Approved: Yes |
| Citroen Model: Dyane Model series: Dyane 6 Size of motor: 0.6 Brand of engine: M28/1 From date: 01-05-1972 To date: 01-12-1980 Fuel: Gasoline Approved: Yes |
| Citroen Model: LNA Model series: LNA Size of motor: 0.6 Brand of engine: R06627 Body: Hatchback From date: 01-11-1976 To date: 01-07-1979 Fuel: Gasoline Approved: Yes |
| Citroen Model: LNA Model series: LNA Size of motor: 0.6 Brand of engine: V06630 Body: Hatchback From date: 01-11-1978 To date: 01-07-1986 Fuel: Gasoline Approved: Yes |
| Citroen Model: LNA Model series: LNA Size of motor: 0.6 Brand of engine: V06644 Body: Hatchback From date: 01-11-1978 To date: 01-07-1986 Fuel: Gasoline Approved: Yes |
| Citroen Model: Mehari Model series: Mehari Size of motor: 0.6 Brand of engine: M28/1 Body: Convertible From date: 01-05-1968 To date: 01-10-1979 Fuel: Gasoline Approved: Yes |
